| Type |
In-line sealed mail making system |
|---|
| Compatible Printer |
ComColor 9150/7150 |
| Finishing Type |
Sealed mail making |
| Size of Envelope Form*1 |
Envelope Form A |
233 mm × 296 mm (approx. 105 gsm) |
| Envelope Form B |
233 mm × 391 mm (approx. 105 gsm) |
| Envelope Form C |
243 mm × 296 mm (9 9/16" × 11 21/32"), approx. 105 gsm (28-lb bond) |
| Insert Paper*1 |
Paper Size |
A4 (210 mm × 297 mm), B5 (182 mm × 257 mm), Legal (8 1/2" × 14"), Letter (8 1/2" × 11") |
| Paper Type and Weight |
Standard tray: Plain paper, recycled paper (46 gsm to 120 gsm (12.2-lb bond to 31.9-lb bond))
Feed tray: Plain paper, recycled paper (52 gsm to 104 gsm (14-lb bond to 28-lb bond)) |
| Maximum Printable Area*1 |
Envelope Form A |
212 mm × 217 mm |
| Envelope Form B |
212 mm × 311 mm |
| Envelope Form C |
222 mm × 217 mm (8 3/4" × 8 17/32") |
| Paper Tray Capacity |
Standard Tray |
Height up to 110 mm (4 5/16") |
| Feed Tray |
Height up to 50 mm (1 15/16") (× 3 trays) |
| High Capacity Feeder
(optional) |
Height up to 440 mm (17 5/16") |
| Mail Stacker Capacity |
Height up to 310 mm (12 7/32") (approx. 110 mails with IJ paper (85 gsm (23-lb bond)), 1 sheet insert with inner 3 folds) |
Number of Insert
Pages*1 |
A4 size |
46 gsm to 59 gsm: 6 sheets or less
60 gsm to 80 gsm: 5 sheets or less
81 gsm to 100 gsm: 4 sheets or less
101 gsm to 120 gsm: 3 sheets or less |
| Letter Size (with tri-fold) |
46 gsm to 59 gsm (12.2-lb bond to 15.7-lb bond): 6 sheets or less
60 gsm to 80 gsm (16-lb bond to 21.3-lb bond): 5 sheets or less
81 gsm to 100 gsm (21.5-lb bond to 26.6-lb bond): 4 sheets or less
101 gsm to 120 gsm (26.9-lb bond to 31.9-lb bond): 3 sheets or less |
| Legal Size (with quad-fold) |
46 gsm to 59 gsm (12.2-lb bond to 15.7-lb bond): 4 sheets or less
60 gsm to 80 gsm (16-lb bond to 21.3-lb bond): 3 sheets or less
81 gsm to 100 gsm (21.5-lb bond to 26.6-lb bond): 2 sheets or less
101 gsm to 120 gsm (26.9-lb bond to 31.9-lb bond): 1 sheet |
| Adhesion Method |
Mail Short-edge Part |
Pressure seal |
| Mail Long-edge Part |
Water glue |
| Remoistening Adhesive |
Water Supply Method |
Replenish from the water supply tank |
| Water Supply Tank Capacity |
400 ml |
| Water Tank Capacity
Inside Printer |
480 ml |
| Finished Mail Size*1 |
Envelope Form A |
233 mm × 110 mm |
| Envelope Form B |
233 mm × 158 mm |
| Envelope Form C |
243 mm × 110 mm (9 9/16" × 4 11/32") |
| Processing Speed*2 |
37 mails/min. |
| Power Source |
AC 100-240 V, 3.0-1.5 A, 50-60 Hz |
| Power Consumption |
Maximum: 250 W |
| Operating Noise*3 |
Max. 68 dB |
| Operating Environment |
Temperature: 15°C to 30°C (59°F to 86°F)
Humidity: 40% to 70% RH (non-condensing) |
| Dimensions (W × D × H) |
990 mm × 710 mm × 940 mm (38 31/32" × 27 15/16" × 37") |
| Required Space with Printer (W × D × H) |
2,255 mm × 1,280 mm × 1,030 mm (88 25/32" × 50 13/32" × 40 9/16") |
| Weight |
Approx. 161 kg |
